Reliable Solution to your power problems
products
Online UPS (uninterruptible power supply)
Range :
| Ph-Ph | 1Ph-1Ph | 3Ph-1Ph | 3Ph-3Ph |
|---|---|---|---|
| Rating | 1KVA/48V | 7.5KVA/240V | 10KVA/360V |
| 2KVA/72V | 10KVA/240V | 15KVA/360V | |
| 2KVA/96V | 10KVA/360V | 20KVA/360V | |
| 3KVA/96V | 15KVA/240V | 25KVA/360V | |
| 5KVA/120V | 15KVA/360V | 30KVA/360V | |
| 5KVA/144V | 20KVA/360V | 40KVA/360V | |
| 5KVA/168V | 25KVA/360V | 50KVA/360V | |
| 7.5KVA/168V | 30KVA/360V | 60KVA/360V | |
| 40KVA/360V | 75KVA/360V | ||
| 50KVA/360V | 100KVA/360V | ||
| 60KVA/360V | 120KVA/600V | ||
| 150KVA/600V | |||
| 200KVA/600V | |||
| 300KVA/600V | |||
| 500KVA/600V |
Features :
- New Generation True Online Double Conversion Sine Wave UPS Systems.
- Designed with latest PWM IGBT based Technology with DSP control.
- Efficient, Reliable & Compact Design.
- Built in Galvanic Isolation Transformer & Static Switch for auto changeover.
- Good Engineering for easy installation, servicing and low MTTR.
- UPS Designed with 10 years of Service Life.
- UPS Designed with Wide Input Range & to operate smoothly in fluctuating Power Conditions in any corner of the country.
- UPS designed with wide input range and operates smoothly with GenSet input.
- User Friendly LCD Monitoring, inbuilt RS232 / RS485 port and optional SNMP, MODBUS and GSM module for monitoring UPS remotely.
- Excellent Charger with Higher Charging Current capabilities (on demand) to ensure longer battery life.
- UPS certified by ETDC, SAMEER, CPRI, COEP.
Online UPS Applications :
UPS designed to support various applications across the entire spectrum of the Industry
- Data centers, ATM’s, High End Servers and Software Development Houses.
- Critical Medical Equipments
- Telecommunication equipments.
- Laboratory & Analytical Equipments.
- Process Control, Instrumentation and Automation Loads.
Industrial UPS
Range :
Range 10 to 500 KVA with 3Ph Input & 3Ph Output
Features :
- True Online Double Conversion Sine Wave UPS Systems.
- UPS designed with latest PWM IGBT based Technology with DSP control.
- Highly Efficient, reliable.
- Built in Galvanic Isolation Transformer & Static Switch for auto changeover.
- Good Engineering for easy installation, servicing and low MTTR.
- UPS Designed with 15 years of Service Life.
- UPS Designed with Wide Input Range & to operate smoothly in fluctuating Power Conditions in any corner of the country.
- Generator Friendly UPS with input PFC and Low THDi.
- Indigenously designed to support Crest Factor, Non-Linear and unbalanced loads with heavy inrush currents.
- User Friendly LCD Monitoring, inbuilt RS232 / RS485 port and optional SNMP, MODBUS and GSM module for monitoring UPS remotely.
- Custom built UPS systems with any Ingress Protection(IP) available on request
UPS Applications :
UPS designed to support various applications across the entire spectrum of the Industry
- Data centers, ATM’s, High End Servers and Software Development Houses.
- Critical Medical Equipments like, CT Scan, MRI, Linear Accelerator & Operation Theatre.
- Industrial loads like Motors, CNC, PLC, DCS, Laser Cutting Machine and Pumps.
- Lighting, Lifts, Air Conditioners & other Electrical Loads.
